FR-4 CNC Machining Service

CNC milling CNC turning Waterjet cutting Grinding

Machined FR-4 glass-epoxy laminate — the flame-retardant laminate specified where electrical insulation and mechanical strength both matter, cut to the tolerance, minimum wall and lead time the shop holds.

Get a quote
Compare all 23 materials

$$Price band

±0.125mmAchievable · ISO 2768

0.80 mmMinimum wall

3–10 daysPublished lead time

FR-4 glass-epoxy laminate sheet stock used for machining

Specifications

FR-4 specifications: ±0.125 mm tolerance, 0.80 mm wall, 3 to 10 days lead time

Six numbers a buyer asks for before sending a drawing — the process, the
tolerance we hold, the minimum wall, the largest envelope, the lead time and the price band.

Process

CNC mill · CNC lathe3-axis and 5-axis milling, turning

Achievable tolerance

Not lower than ±0.125mm (±0.005″)Based on the drawing, ISO 2768

Minimum wall

0.80 mmVaries with the wall-to-linear-dimension ratio

Maximum part size

200 × 80 × 100 cmLargest envelope quoted online

Lead time

3–10 daysComplex parts sit at the far end

Price band

$$Where FR-4 sits against the other 22 materials

Read this first. Process, maximum part size and lead time are
identical on all 23 material pages — they describe the shop, not the material. Tolerance,
minimum wall and price band are the three that change from one material to the next.
This page publishes no grade list, so there is no grade table below — name the
grade you want on the drawing instead.

Machining routes

Machining routes for FR-4: milling, turning, waterjet cutting and grinding

Milling and turning are what this page is quoted on. The routes below are the ones the same material takes when the stock form, the volume or the lead time changes — each one is a service page on this site.

CNC millingQuoted here3-axis and 5-axis milling of FR-4 sheet — board outlines, pockets, cut-outs and drilled patterns.CNC machining →

CNC turningQuoted hereSleeves, bushes and spacers from FR-4 tube and rod stock.CNC turning →

Waterjet cuttingSheet stockThe right way to blank a laminate: an abrasive jet cuts without the heat that chars the epoxy.Waterjet cutting →

GrindingFinishing passSurface grinding to bring sheet thickness and cut edges into a tighter band; the grinding page covers composites as well as metals.Grinding →

Not used for FR-4:Injection molding, die casting, vacuum casting and EDM. FR-4 is a cured thermoset glass-epoxy laminate — it cannot be melted and re-formed — and the resin is an electrical insulator.

Which polymer?

FR-4, G-10 or PEI: choosing by insulation, heat and flame rating

Each answer points at a page on this site that covers it in more depth — a
comparison, a grade guide or a process page.

Is the flame rating the requirement?

Then FR-4 is the laminate to specify: the same woven-glass reinforcement as G-10, with a flame-retardant epoxy system. The Garolite page here is the general-purpose sibling without that rating.

Garolite laminates Material selection guide

Compare with Garolite →

Does it have to survive a high-temperature process or a cleanroom bake?

Then the high-temperature polymers are the comparison — PEI and PEEK are both published on this site and both hold their dimensions far above where a laminate resin does.

PEI (ULTEM)PEEK

Compare with PEI →

Is it for electrical equipment rather than a structural part?

The insulating polymers are the comparison: PPS and PPSU are the pages here bought for electrical and high-temperature service.

PPS PPSU

Compare with PPS →

Circuit-board work rather than a machined part?

Then the substrate is drilled, routed and profiled rather than turned. The design guide covers how the panel is specified before it is cut.

Design guide All 23 materials

See all 23 materials →
